Medical Workstation

Your Professional Medical Workstation Supplier

We are a specialized foreign trade manufacturer in the life and health industry, dedicated to the independent research, development, production, and sales of high-quality products that cover the entire medical and healthcare supply chain. Since our establishment, we have remained committed to technological innovation and excellence, striving to provide global customers with premium products and outstanding services.

Full industry chain coverage

Our products cover medical diagnosis, in vitro diagnostic equipment, biosafety protection, disinfection and sterilization, purification engineering, cold chain transportation and medical beauty products, truly realizing a one-stop solution.

Authoritative certification guarantee

The products have passed international certifications such as EU CE, EN, US NSF, FDA, etc., and the quality standards strictly meet the needs of the global market, winning high recognition from international customers.

Global layout

Our business covers more than 190 countries and regions around the world. With an efficient international supply chain and customer service network, we ensure a quick response to global customer needs.

Leading in technology and R&D

We always adhere to technology-driven, continue to increase R&D investment, ensure that our products always maintain high quality and high performance, and can meet the diversified needs of different markets.

Pathology Workstation

The pathology workstation bench is widely used in hospital pathology departments, pathology laboratories, etc. A reasonable ventilation system protects the operator from the harmful gases produced by formalin during sampling. The hot and cold water system ensures it can adapt to different climates.

Pathology Workstation

Model		QCT-1000	QCT-1500	QCT-1800
*External Size (WDH)*		10007501950mm	15007501950mm	18007501950mm
*Working Area Size (WDH)*		895430900mm	1395430900mm	1695430900mm
Work Surface Height		900mm
Consumption		250W	300W	300W
Optional water heater		1500W
Power Supply		AC220V±10%, 50/60Hz; 110V±10%, 60Hz
Exhaust Airflow Volume		500-600m3/h
Material	Main Body	304 stainless steel
	Work Table	304 stainless steel
	Standard Accessories	Spotlight; UV lamp; Fluorescent lamp; Exhaust system; 4m exhaust duct; Pipe strap; Auto flushing device; Stainless steel hanger; Adjustable hot and cold water tap; 180mm deep stainless steel water sink, funnel with filter. Active carbon filter
	Optional Accessories	Pulverizer, Electrical water heater, Automatic induction hand dryer, Eye washer, Camera. Flex magnifier light, laptop bracket
*Package Size(WDH)mm*		11608902170	16608902170	19608902170
Gross Weight		250kg	300kg	340kg

Advantages

●Odor-removal function.
●Single water sink, capable of supporting two-person operation.
●Exhaust air system: High-power suction device with low noise.
●The base cabinet is inward-concave, making it convenient for seated operation.
●Automatic flushing device with a slightly right-tilted worktable, making it easy for waste discharge and cleaning.
●Optional water heater available, allowing hot and cold water adjustment.

●Optional pulverizer that can completely crush waste during testing to avoid blocking drainage pipes.

Gas Cylinder Cabinet

The gas cylinder cabinet is a metal container used to improve local exhaust ventilation, protect steel cylinders (gas cylinders) from fire outside the cabinet and protect surrounding objects from internal fire.

Flammable storage cabinets feature reinforced 18-gauge steel, with double-wall internal and external welded construction and a 1-1/2 inch air space on the sides, top, bottom, back, and doors. Four adjustable galvanized leveling legs and a ground connection keep the cabinet stable.

The patented safety shelving includes adjustable galvanized steel shelves that direct spills to the back and bottom of the leakproof sump. Each shelf holds up to 350 lbs. UDL and has 3-inch centers for shelf brackets.

The fire-resistant cabinet has a lead-free, high-gloss, baked-on powder finish with trilingual warning labels. It also features a 2-inch raised leakproof door sill, two 2-inch internal vents with fire baffles and caps, and fail-safe doors.

The cabinet is available with either manual-close doors (180° opening) or self-closing doors (135° opening) that self-latch. It also includes a three-point stainless steel bullet-latching system, piano hinges, and a flush-mounted door handle with a key lock.

Product Parameters

Model No.	Description	External Dim H x W x D(mm)	No. of Gas Cylinders	Door(s)	Weight (kg)
Model No.	Description	External Dim H x W x D(mm)	No. of Gas Cylinders	Door(s)	Weight (kg)
APL-QPG-1	Full steel gas cylinder cabinet	1900600450	1	Single	50
APL-QPG-2	Full steel gas cylinder cabinet	1900900450	2	Double	100
APL-QPG-3	Full steel gas cylinder cabinet	19001200450	3	Double	150
APL-QPG-4	Full steel gas cylinder cabinet	19001500450	4	Double	200
APL-FBQPG-1	Full steel explosion proof gas cylinder cabinet	1900600450	1	Single	50
APL-FBQPG-2	Full steel explosion proof gas cylinder cabinet	1900900450	2	Double	100
APL-FBQPG-3	Full steel explosion proof gas cylinder cabinet	19001200450	3	Double	150
APL-FBQPG-4	Full steel explosion proof gas cylinder cabinet	19001500450	4	Double	200

Production name	Explosion-Proof Cabinet
Model No. and Color Options	BLS090/Yellow
Capacity	90 gallons/340Liter
Door Type	Manual closing
1	2
Adjustable Shelves	Yes
Dimensions(Exterior)	W1090D860H1650(mm)
Dimensions(Interior)

Usage	Used for oil-containing drums
Adjustable shelf	Anti-overflow shelves;Prevent accidental leaked chemicals spilling
Configuration	Equipped with a set of detachable rollers and an adjustable shelf
Ventilation design	Fireproofing vent
Door Lock Design	Three-point linkage door lock,make opening and closing more flexible
Stainless Steel Anti-corrosion Hinges	The door can be opened to a maximum of 180 degrees
Weight	190KGS

Key Features of the Gas Cylinder Cabinet

Robust Construction: The gas storage cabinet is built using high-quality materials, such as steel or other suitable alloys, ensuring durability and structural integrity. The sturdy construction provides reliable protection against external elements and potential accidents.

Ventilation System: Proper ventilation is crucial when storing hazardous gases to minimize the risk of accumulation or leaks. The cabinet is equipped with a ventilation system designed to facilitate air circulation and effectively remove any gas fumes or vapors that may be present.

Secure Locking Mechanism: Safety is of utmost importance when storing hazardous gases, and the cabinet features a secure locking mechanism to prevent unauthorized access. This can include key locks, combination locks, or electronic locks, depending on the specific model or customer preference.

Adjustable Shelving: The interior of the cabinet typically includes adjustable shelves or racks to accommodate gas cylinders or containers of different sizes. This allows for efficient use of space and ensures proper organization and easy retrieval of stored gases.

Flame Arrestors: To enhance safety measures, the gas storage cabinet may incorporate flame arrestors. These devices help prevent flames or sparks from entering the cabinet, minimizing the risk of fire or explosions caused by external ignition sources.

Compliance with Safety Standards: The gas storage cabinet is designed and manufactured to comply with industry-specific safety standards, ensuring that it meets all necessary requirements for safe gas storage. This includes adherence to regulations regarding ventilation, labeling, and handling hazardous materials.

Clear Labeling and Signage: The cabinet features clear labeling and signage to indicate the type of gases being stored, as well as any precautions or handling instructions. This helps users identify and handle the gases safely, reducing the chance of accidents or mix-ups.

Optional Safety Accessories: Depending on the specific needs of the user, additional safety accessories may be available for the gas storage cabinet. Examples include gas leak detectors, fire suppression systems, or gas monitoring equipment to further enhance safety precautions.

Easy Maintenance: Regular maintenance is essential to ensure the continued safety and functionality of the gas storage cabinet. The design of the cabinet facilitates easy cleaning and inspection, allowing for simple maintenance tasks, such as wiping down surfaces or checking ventilation systems.

Certificates

FAQ

Q: May l customize the size of a product?

A: Yes, we provide customized service based on our experiences for 25+ years.Please send the drawing and specification you requirewe can discuss the further requirement, and then we can start tomanufacture.

Q: What is your term of delivery?

A: We accept EXW, FOB Taichung, or ClF

Q: What's the lead time for mass production?

A: It depends on the order quantity and the season you place theorder.

Q: May I have a sample before mass production?

A: We provide free samples for some products, and we can custom-ize the sample according to your requirements.

Q: How long is the warranty period?

A: We offer one year warranty, including spare parts are given freereplacement; electrical products are free to be replaced or repairedwithin 3 months.

We're well-known as one of the leading medical workstation suppliers in China. Please feel free to buy high quality medical workstation in stock here from our factory. For customized service, contact us now.
