The Cytotoxic Safety Cabinet is an indispensable piece of equipment for laboratories involved in microbiological research, biomedical studies, DNA recombination, animal experiments, and biopharmaceutical production. Particularly suitable for environments like medical health and medical research, where protective measures are critical, this cabinet ensures a sterile, dust-free working environment for tasks such as bacterial culturing, safeguarding both operators and the laboratory environment. Designed to meet international standards, the work surface is set at 750mm in height, with custom height options available upon request.
Equipped with precise airflow control, the Cytotoxic Safety Cabinet features an average downward airflow velocity of 0.33±0.025m/s and an intake airflow velocity of 0.53±0.025m/s, ensuring a stable negative pressure environment. With a total exhaust airflow of 620m³/h, a rated power of 1800W (including a 500W load for operational outlets), and a noise level of ≤67dB(A), it provides quiet yet efficient operation. The cabinet's illumination reaches 1000lx, offering optimal visibility for precise work.
To ensure optimal protection, the Cytotoxic Safety Cabinet is equipped with ULPA high-efficiency filters made from borosilicate glass fiber, with a filtration efficiency of ≥99.9995% for particles as small as 0.12μm. This ensures a contaminant-free environment, while the cabinet's biological safety features meet rigorous standards, achieving a protection factor of no less than 1×10⁵ for the front window operation port. With a colony count of ≤5CFU/operation, cross-contamination is minimized, ensuring product and personnel safety. Certified with the National Medical Device Registration (number: 20163222133), this cabinet is designed for use by 1-3 operators and provides reliable and efficient laboratory safety protection.
Technical Parameters
|
Model |
11224BBC86 |
11234BBC86 |
11244BBC86 |
|
External Size (W*D*H) |
1087*760*2100mm |
1380*760*2100mm |
1877*760*2100mm |
|
Internal Size (W*D*H) |
910*600*630mm |
1220*600*630mm |
1700*600*630mm |
|
Tested Opening |
Safety height 200mm(8") |
||
|
Max Opening |
440mm(17") |
||
|
Inflow Velocity |
0.53±0.025m/s |
||
|
Down Flow Velocity |
0.33±0.025m/s |
||
|
Exhaust Volume |
347m³/h |
465m³/h |
648m³/h |
|
Air Supply Filter |
ULPA filter, efficiency>99.9995% for particle size at 0.12μm |
||
|
Exhaust Filter |
ULPA filter: first exhaust filter: 0.12μm efficiency 99.9995%; HEPA filter: secondary exhaust filter: 0.3μm efficiency 99.995% |
||
|
Alarm |
Abnormal airflow velocity, Filter replacement, Front window at unsafe height, High filter pressure alarm |
||
|
Noise |
≤67dB |
||
|
Water&Gas Tap |
Water tap*1, Gas tap*1 |
||
|
UV Lamp |
20W*1 |
30W*1 |
40W*1 |
|
Emission of 253.7 nanometers for most efficient decontamination UV life indicator, UV timer |
|||
|
LED Lamp |
12W*2 |
14W*2 |
16W*2 |
|
Illumination |
≥1000Lux |
||
|
Consumption |
700W |
900W |
1300W |
|
Waterproof Socket |
Two, total load of two sockets: ≤500W |
||
|
Display |
LCD display |
||
|
Control System |
Microprocessor |
||
|
Humidity and Temperature |
Humidity and temperature can be displayed on the control panel |
||
|
Material |
Work Area: 304 stainless steel Main Body: cold-rolled steel with anti-bacteria powder coating |
||
|
Front Window |
Motorized, two-layer laminated toughened glassN6mm, anti-UV |
||
|
Caster |
Footmaster caster |
||
|
Power supply |
AC220V±10%, 50/60HZ; 110V±10%, 60Hz |
||
|
Standard Accessory |
Base stand, Drain valve, Waterproof sockets*2, Remote control, LED lamp*2, UV lamp*2, Water tap, Gas tap |
||
|
Optional Accessory |
Armrest, Formalin fumigation sterilizer, Infrared sterilizer, Airflow tester |
||
|
Gross Weight |
320kg |
371kg |
430kg |
|
Package Size (W*D*H) |
1240*910*2280mm |
1540*910*2280mm |
2050*910*2260mm |
